DISCOVER S100 Embedded Series
  |
 |
Embedded OS
|
|
Embedded MCU
|
|
High performance DSP with
hardware compression
|
|
H.264 video compression
|
|
Multi-zone motion
detection
|
|
Privacy masking function
|
|
Video loss alarm
|
|
Support up to 8 IDE hard
disk (max 2,000GB each)
|
|
Support hard disk sleep
mode
|
|
Support hard disk SMART
monitoring
|
|
Individually selectable
recording mode
|
|
Support external USB
device (hard disk, thumb drive..)
|
|
Composite and VGA video
output
|
|
Support TCP, UDP, RTP,
Multicast, DHCP etc
|
|
Support ADSL (PPPoE) dial
up
|
|
Support PSTN dial up
|
|
Support local and remote
PTZ control
|
|
Watch dog feature
|
|
Remote parameters setup
|
|
Remote upgrade firmware
|
|
IE browser support
|
|
Support network audio
communication
|
|
Support multi-level users
management
|
Specification
|
Model
|
DIS-S104
|
DIS-S108
|
DIS-S112
|
DIS-S116
|
DIS-S104D
|
DIS-S108D
|
DIS-S112D
|
DIS-S116D
|
|
Video Compression
Standard
|
MPEG-4 Part 10 H.264
|
|
Recording Resolution
|
PAL: 352 x 288 (CIF)
NTSC: 352 x 240 (CIF)
|
PAL: 704 x 576 (4-CIF)
NTSC: 704 x 480 (4-CIF)
|
|
Composite Video Input
|
4
|
8
|
12
|
16
|
4
|
8
|
12
|
16
|
|
Composite Video
Output
|
1 channel, 1.0 Vp~p,
75ohm
|
|
Frame Rate
|
PAL: 25 fps, NTSC: 30 fps
|
|
Bit Rate
|
32~2Mbps (self
definition)
|
|
Audio Input
|
4
|
8
|
12
|
16
|
4
|
8
|
12
|
16
|
|
Audio Output
|
1 channel, BNC (line out,
600ohm)
|
|
Audio Compression
|
OggVorbis, 16kbps
|
|
Voice Interface
|
1 BNC (line in, 1,000
ohm)
|
|
Communication
Interface
|
1 RJ45 10/100M UTP
network port, 1 RS232 port, 1 RS485 port
|
|
Keyboard Interface
|
1 RJ45 port
|
|
Device Expansion
|
1 RJ45 port
|
|
Hard disk IDD
Interface
|
8 SATA socket, support up
to 8 SATA interface hard disk (each up
to 2,000 GB)
|
|
USB Interface
|
1 USB port (version 1.1
compliant), support USB flash disk, USB
removable media (eSATA as optional)
|
|
VGA Output
|
1, maximum resolution :
1280 x 1024
|
|
Alarm Input
|
8
|
8
|
16
|
16
|
8
|
8
|
16
|
16
|
|
Alarm Output
|
4
|
|
Power Supply
|
90~135 VAC or 180~265 VAC,
47~63 Hz
|
|
Power Consumption
|
22~42 W (without hard
disk)
|
|
Operating Temperature
|
-10°C ~ +50°C
|
|
Humidity
|
10% ~ 90%
|
|
Dimension
|
19" standard (450 x 450 x
95mm)
|
|
Weight
|
Approx 8.0 kg (without
hard disk)
|
|
|
|
|
